model | wheel material | diameter | wheel width | installation height | rotation radius | base plate size | mounting holes | thread rod spec. | bore | load capacity [kg] | ||||
| pp | pa | pu | pvc | tpr | ||||||||||
| 1.5" | pp, pa, pu, pvc, tpr | 40 | 22 | 60 | 51 | 60×43 | 44×30 | m8/m10*25 | 6.3 | 35 | 40 | 40 | 35 | 35 |
| 2" | pp, pa, pu, pvc, tpr | 50 | 25 | 73 | 54 | 71×51 | 51×35 | m8/m10*25 | 8 | 50 | 55 | 55 | 50 | 50 |
2.5" | pp, pa, pu, pvc, tpr | 65 | 32 | 91 | 64 | 92×64 | 73×45 | m10/m12*30 | 8.5 | 70 | 75 | 75 | 70 | 70 |
3" | pp, pa, pu, pvc, tpr | 75 | 32 | 102 | 66 | 92×64 | 73×45 | m10/m12*30 | 8.5 | 75 | 80 | 80 | 75 | 75 |
4" l | pp, pa, pu, pvc, tpr | 100 | 32 | 128 | 77 | 92×64 | 73×45 | m10/m12*30 | 8.5 | 85 | 90 | 90 | 85 | 85 |
5" | pp, pa, pu, pvc, tpr | 125 | 32 | 152 | 91 | 92×64 | 73×45 | m10/m12*30 | 8.8 | 95 | 100 | 100 | 95 | 95 |
note: pp=polypropylene, pa=nylon (polyamide), pu=polyurethane, pvc=polyvinyl chloride, tpr=thermoplastic rubber. | ||||||||||||||
