specification | wheel material | diameter [mm] | wheel width [mm] | installation height [mm] | base plate size [mm] | mounting hole [mm] | bore diameter [mm] | load capacity [kg] | ||
| swivel | rigid | swivel | rigid | |||||||
| 1.5 inch | pa nylon | 37 | 24 | 51 | 61×44 | 61×36 | 48×23 | 48×23 | 5.5 | 30 |
| 2 inch | pa nylon | 46 | 24 | 62 | 65×48 | 67×38 | 53×24 | 53×24 | 5.5 | 40 |
2.5 inch | pa nylon | 63 | 27 | 80 | 96×67 | 99×52 | 75×40 | 81×25 | 5.5 | 50 |
3 inch | pa nylon | 75 | 31 | 92 | 105×77 | 104×59 | 85×58 | 84×36 | 5.5 | 60 |
