b01755137-3
| specification | caster material | diameter | wheel width | installation height | rotation radius | base plate size | mounting holes | screw rod specification | hole diameter | load capacity [kg] | ||||||
| pp | pa | np | pu | pvc | tpr | pl | ||||||||||
| 2.5 inch | pp,pa,np,pu,pvc,tpr,pl | 65 | 32 | 91 | 64 | 92×64 | 73×45 | m10/m12*30 | 8.5 | 70 | 75 | 70 | 75 | 70 | 70 | 85 |
| 3 inch | pp,pa,np,pu,pvc,tpr,pl | 75 | 32 | 102 | 66 | 92×64 | 73×45 | m10/m12*30 | 8.5 | 75 | 80 | 75 | 80 | 75 | 75 | 90 |
| 3.5 inch | pp,pa,np,pu,pvc,tpr,pl | 90 | 32 | 119 | 74 | 92×64 | 73×45 | m10/m12*30 | 8.5 | 80 | 85 | 80 | 85 | 80 | 80 | 95 |
| 4 inch | pp,pa,np,pu,pvc,tpr,pl | 100 | 32 | 128 | 77 | 92×64 | 73×45 | m10/m12*30 | 8.5 | 85 | 90 | 85 | 90 | 85 | 85 | 100 |
| 5 inch | pp,pa,np,pu,pvc,tpr,pl | 125 | 32 | 152 | 91 | 92×64 | 73×45 | m10/m12*30 | 8.8 | 95 | 100 | 95 | 100 | 95 | 95 | 110 |
| note: pp=polypropylene, pa=nylon, np=rubber, pu=polyurethane, pvc=polyvinyl chloride, tpr=thermoplastic rubber, pl=cast iron wheel. | ||||||||||||||||
